Muaj 70 / 530- mpb ib kab angular chldro
Lub ntsiab
Angular sib cuag pob bearings nrog cov qauv tseem ceeb tseem ceeb sib haum rau din 628-1.
Lub sab thiab geometrical torances ntawm tus qauv bearings sib xws rau kev tiv thaiv chav kawm pn rau din 620-2.
Tib cov kabmob tib yam 70 / 530- mpb-p6, 70/530; 70/530 BM, yog muaj av.
Ib Leeg 800 ..- MPB series nrog MP-tooj dag khoom ncaj hnab tshos tawb, sab hauv nplhaib qhia; Lub tawb tooj dag no muaj lub zog zoo thiab lub zog kub ua kom cov kab mob ruaj khov thiab hloov kho kom sov nrawm. Tsis kaw; Cov kabmob no tuaj yeem siv thaum muaj kev ua haujlwm ntawm -30 degree rau +200 degree (nws lub nplhaib nyob ruaj khov rau xyoo 200 degree). Kam rau chav kawm (PN). Yuav tiv taus radial thiab unidirectional axial thauj khoom, kabmob tsis yog roj.
Kev Ntsuas Qhov Loj {{0}} mm; Sab nraud lub taub -780 hli; dav -112 hli; Mass -185 kg; cr =860}}}}}} 680 1}}}}}}}}}}}}}}}}}}}}}
Cov lus qhia
| Qhov loj thiab kev ua haujlwm datasheets | |
| Ntu tsis muaj. | 70 / {530- mpb-ib Lis angular tiv toj cov kabmob npas |
| Hom | Fag hom ua hauv lub teb chaws Yelemees / sdvv hom ua nyob rau hauv Suav teb |
| Qhov loj me | 530x7x7x112 hli |
| d | 530 hli |
| D | 780 hli |
| B | 112 hli |
| rmin | 6 hli |
| D1 | 691.3 hli |
| Hu rau kaum | 30 Degree |
| da min. | 553 hli |
| Da max. | 757 hli |
| ra max. | 5 hli |
| Cr | 860 kn |
| C0r | 2140 Kn |
| M | 185 kg |
