32244-A Nrog Loj 220x400x114mm Ib Kab Tapered Cov Menyuam Bearing
Txheej txheem cej luam
322 series Ib -kab tapered menyuam bearings; Qhov loj me raws li DIN 720, cov qauv sib cais; suav nrog cov khoom sab hauv thiab sab nrauv nrog cov kab sib tw sib tw thiab cov hlua khi nrog cov tawb ua los ntawm cov ntawv xovxwm nias; lub qhov rai tawb, cov menyuam -guided.Normal (ISO 492: 2014) chav kawm kam rau ua.
Lub taub hau - 200 mm; Sab nraud txoj kab uas hla-400 hli; Dav-114 hli; Mass-59.6 kg;Cr=1820 kN;C0r=2550 kN;Cur=310 kN.
Interchangeable bearing code No.32244-XL kuj muaj nyob rau hauv Tshuag.
Specifications
| Dimensions & Technical Datasheets | |
| Tshooj NO. | 32244-A - Ib Kab Tapered Cov Menyuam Bearing |
| Hom | FAG ua nyob rau hauv GERMANY thiab SDVV / ZBM hom ua nyob rau hauv Suav teb |
| Main Dimensions | 220 x 400 x 114 mm |
| d | 220 hli |
| D | 400 hli |
| T | 114 hli |
| C | 90mm ua |
| B | 108 hli |
| da max | 258mm ua |
| r1,2 nqi | 5 hli |
| r 3, 4m | 4 hli |
| Cr | 18 20 kNv |
| C0r | 2550 kN ib |
| Cur | 310kn ua |
| M | 5 9,6kg |
