SL182980-TB-BR-C3 Nrog Loj 400x540x82 mm Ib Leeg Ib Leeg Tag Nrho Cov Cylindrical Cov Menyuam Bearing
Txheej txheem cej luam
Lub bearings SL1829.
TB-Bearings nrog nce axial load peev;
C3-Radial internal clearance yog loj dua li qub.
Lub taub hau - 400 mm; Sab nraud txoj kab uas hla-540 hli; Dav-82 hli; Mass-52.5 kg;Cr=1710 kN;C0r=3500 kN; txwv ceev=650 1/min; Siv ceev=350 1/min.
Cov hom muaj feem xyuam: SL182980-TB-C3, SL182980-B-C3, thiab SL182980 kuj tau npaj rau hauv Tshuag rau koj daim ntawv thov tshuab xav tau.
Specifications
| Dimensions & Technical Datasheets | |
| Tshooj NO. | SL182980-TB-BR-C3-Ib Kab Ib Leeg Tag Nrho Cov Cylindrical Cov Menyuam Bearing |
| Hom | INA ua nyob rau hauv GERMANY thiab SDVV / ZBM hom ua nyob rau hauv Suav teb |
| Main Dimensions | 400 x 540 x 82 mm |
| d | 400 hli |
| D | 5 40mm |
| B | 82mm ua |
| rmin ua. | 4 hli |
| da | 450 hli |
| Da | 4 96mm |
| Cr | 1 710kn |
| C0r | 3500 kN ib |
| Cur | 360kn ua |
| Txwv ceev | 650 1/min |
| Siv ceev | 350 1/min |
| M | 5 2,5kg |
NtauIb Kab Tag Nrho Cov Cylindrical Cov Menyuam Bearing Rau Koj Siv
| Lub npe | Pawg m ≈ kg |
Qhov ntev | ||||
| d | D | B | r min. |
s1) | ||
| SWB 181880-E | 1,981 | 400 | 500 | 46 | 21 | 4 |
| TIAB SA 182980 | 543 | 400 | 540 | 82 | 4 | 5 |
| SL183080-TB | 140 | 400 | 600 | 148 | 5 | 18 |
| SIB 181884-E | 206 | 420 | 520 | 46 | 21 | 4 |
| TIAB SA 182984 | 569 | 420 | 560 | 82 | 4 | 5 |
| SIB 181888-E | 2,154 | 440 | 540 | 46 | 21 | 4 |
| TIAB SA 182988 | 781 | 440 | 600 | 95 | 4 | 7 |
| SIB 181892-E | 3,321 | 460 | 580 | 56 | 3 | 5 |
| TIAB SA 182992 | 811 | 460 | 620 | 95 | 4 | 7 |
| SIB 181896-E | 3,453 | 480 | 600 | 56 | 3 | 5 |
| TIAB SA 182996 | 947 | 480 | 650 | 100 | 5 | 7 |
| SL1818/500-E | 3,573 | 500 | 620 | 56 | 3 | 5 |
