Z-511991.TR2 Nrog Loj 300x500x205 mm Ob chav kab Tapered Cov Menyuam Bearing
Txheej txheem cej luam
Tsim 7:
■ Bearings nrog cov ntawv hlau tawb thiab sab hauv nruab nrab nplhaib.
■ Lubrication zawj thiab lubrication qhov nrog rau qhov tuav lub qhov
nyob rau hauv lub nplhaib sab nrauv.
Ob chav kab tapered menyuam bearings hauv O-kev npaj; tsis muaj cov ntsaws ruaj ruaj; kub ntawm -30℃mus rau +150 degree, nyob ntawm cov roj nplua nyeem.
Lub taub hau - 300 mm; Sab nraud txoj kab uas hla-500 hli; Dav-205 hli; Mass-145 kg;Cr=2700 kN;C0r=5300 kN;Cur=510 kN.
Specifications
| Dimensions & Technical Datasheets | |
| Tshooj NO. | Z-511991.TR2 - Ob Chav Kab Tapered Cov Menyuam Bearing |
| Hom | FAG ua nyob rau hauv GERMANY thiab SDVV / ZBM hom ua nyob rau hauv Suav teb |
| Main Dimensions | 300 x 500 x 205 mm |
| d | 300 hli |
| D | 500 hli |
| T | 205 hli |
| C | 152 hli |
| e | 0.37mm ib |
| r 1, r2m. | 6 hli |
| r 3, 4m | 2.5 hli |
| Cr | 2 700 kN |
| C0r | 5 300kn |
| Cur | 510kn ua |
| M | 1 45kg |
Tib hom hauv qab no kuj muaj
| Lub npe | Tsim | Pawg m ≈ kg |
Qhov ntev | |||||
| d | D | T | C | r1,r2 min. |
r3,r4 min. |
|||
| Z-511990.TR2 Z-565735.TR2 Z-511991.TR2 |
7 | 638 | 300 | 420 500 500 |
159 180 205 |
128125 | 4 | 1 |
| 6 | 121 | 300 | 95 | 25 | ||||
| 7 | 145 | 300 | 152 | 6 | 25 | |||
| Z-532655.TR2 | 6 | 726 | 340 | 460 | 160 | 128 | 4 | 15 |
| Z-549929.TR2 | 6 | 126 | 340 | 520 | 180 | 135 | 6 | 2 |
| Z-511992.TR2 | 6 | 228 | 340 | 580 | 242 | 170 | 6 | 2 |
| Z-541911.TR2 | 7 | 208 | 350 | 590 | 200 | 140 | 12 | 25 |
| Z-511993.TR2 | 7 | 733 | 360 | 480 | 160 | 128 | 4 | 15 |
| Z-525858.TR2 | 6 | 135 | 360 | 540 | 185 | 140 | 5 | 15 |
| Z-566764.TR2 | 10 | 540 | 3,675 | 6,477 | 410 | 336 | 48 | 33 |
| Z-566765.TR2 | 11 | 540 | 3,675 | 6,477 | 410 | 336 | 48 | 32 |
| Z-538179.TR2 | 7 | 864 | 380 | 520 | 149 | 112 | 5 | 2 |
| Z-511994.TR2 | 6 | 244 | 380 | 620 | 242 | 170 | 5 | 2 |
| F-808453.TR2 | 7 | 236 | 381 | 59,055 | 245 | 190 | 64 | 15 |
| Z-565736.TR2 | 6 | 146 | 400 | 590 | 185 | 125 | 6 | 25 |
| Z-511995.TR2 | 7 | 183 | 400 | 600 | 206 | 150 | 6 | 2 |
| Z-549965.TR2 | 7 | 192 | 420 | 620 | 206 | 150 | 6 | 5 |
| Z-511996.TR2 | 7 | 365 | 420 | 700 | 275 | 200 | 6 | 2 |
| Z-511997.TR2 | 7 | 219 | 440 | 650 | 212 | 152 | 8 | 3 |
| Z-579097.TR2 | 11 | 244 | 447,675 | 635 | 257,175 | 206,375 | 64 | 15 |
| Z-549964.TR2 | 7 | 135 | 460 | 620 | 170 | 131 | 5 | 4 |
| Z-534866.TR2 | 7 | 255 | 460 | 680 | 230 | 175 | 75 | 3 |
| Z-511998.TR2 | 7 | 152 | 480 | 650 | 180 | 130 | 5 | 2 |
| Z-573216.TR2 | 10 | 255 | 480 | 680 | 238 | 190 | 4 | 3 |
| Z-541912.TR2 | 7 | 141 | 490 | 640 | 180 | 144 | 95 | 3 |
| Z-539031.TR2 | 7 | 162 | 500 | 670 | 180 | 130 | 5 | 2 |
| Z-544199.TR2 | 6 | 281 | 500 | 720 | 236 | 180 | 75 | 3 |
| Z-539117.TR2 | 7 | 225 | 520 | 740 | 190 | 120 | 3 | 3 |
| Z-510043.TR2 | 7 | 189 | 530 | 710 | 190 | 136 | 6 | 25 |
| Z-532951.TR2 | 7 | 236 | 560 | 750 | 213 | 156 | 6 | 25 |
| Z-578732.TR2 | 7 | 418 | 560 | 820 | 260 | 185 | 75 | 3 |
| Z-541806.TR2 | 6 | 416 | 560 | 820 | 270 | 190 | 95 | 3 |
