7008CE/HCP4AH1 super precision angular hu rau pob bearing specification
| Lub npe | 7008 CE/HCP4AH1 | |
| Qeb | ||
| Angular Sib cuag Pob Bearing, super-precision | ||
| Qhov ntev | ||
| d (Txoj kab uas hla) | 40 mm | 1, 575 ib |
| D (Sab nraud txoj kab uas hla) | 68mm ib | 2, 677 ib |
| B (dav) | 15 hli | 0.591 nyob rau hauv |
| W (qhov hnyav) | 0.17 kg | 0.37 lbs |
| Technical Data | ||
| Cr (kN) Basic dynamic load ntsuam xyuas | 12.4 | |
| C0r (kN) Basic static load rating | 7.65 | |
| Fatigue load txwv (kN) | 0.236 | |
| Txaus siab rau roj lubrication (r / min) | 36 000 | |
| Tau txais kev ceev rau roj-cua lubrication (r / min) | 56 000 | |
| Sib cuag lub kaum sab xis | 15 degree | |
| Pob qhov taub (mm) | 7, 144 mm | |
| Cov pob | 19 | |
| Siv roj kom muaj nuj nqis | 2.8cm3 ua | |
| foob | Tsis muaj | |
| Precision | P4 | |
Ntxiv 7008.CE.HCP4AH1 angular hu rau pob bearing 40 * 68 * 15
| Lub npe | Thawj qhov loj me | Basic load ntsuam xyuas | Ua tau nrawm | ||||
| dynamic | zoo li qub | Roj lubrication | Roj-cua lubrication | ||||
| d [mm] | D [mm] | B [mm] | C[kN] | C{{0} [kN] | [r/min] | [r/min] | |
| S7008 CB/P4A | 40 | 68 | 15 | 7.41 | 5.6 | 28 000 | |
| 7008 CWB/HCP4A | 40 | 68 | 15 | 7.41 | 5.6 | 34 000 | 53 000 |
| 7008 CWB/HCP4AL | 40 | 68 | 15 | 7.41 | 5.6 | 34 000 | 53 000 |
| S7008 CB/HCP4A | 40 | 68 | 15 | 7.41 | 5.6 | 34 000 | |
| 7008 AWV/P4AH1 | 40 | 68 | 15 | 11.7 | 7.2 | 27 000 | 41 000 |
| 7008 UAS/P4AL | 40 | 68 | 15 | 11.7 | 7.2 | 27 000 | 41 000 |
| 7008 UAS/P4AL1 | 40 | 68 | 15 | 11.7 | 7.2 | 27 000 | 41 000 |
| 7008 UAS/HCP4AH1 | 40 | 68 | 15 | 11.7 | 7.2 | 32 000 | 50 000 |
| 7008 ACE/HCP4AL UAS | 40 | 68 | 15 | 11.7 | 7.2 | 32 000 | 50 000 |
| 7008 ACE/HCP4AL1 | 40 | 68 | 15 | 11.7 | 7.2 | 32 000 | 50 000 |
