71907ACB/HCP4A super precision angular hu rau pob bearing specification
| Lub npe | 71907-ACB/HCP4A | |
| Qeb | ||
| Angular Sib cuag Pob Bearing, super-precision | ||
| Qhov ntev | ||
| d (Txoj kab uas hla) | 35 hli | 1.378 ib |
| D (Sab nraud txoj kab uas hla) | 55mm ua | 2.165 ib |
| B (dav) | 10 mm | 0.394 nyob rau hauv |
| W (qhov hnyav) | 0.074 kg | 0.16 lbs |
| Technical Data | ||
| Cr (kN) Basic dynamic load ntsuam xyuas | 4.88 | |
| C0r (kN) Basic static load rating | 3.45 | |
| Fatigue load txwv (kN) | 0.106 | |
| Txaus siab rau roj lubrication (r / min) | 36 000 | |
| Tau txais kev ceev rau roj-cua lubrication (r / min) | 56 000 | |
| Sib cuag lub kaum sab xis | 25 degree | |
| Pob qhov taub (mm) | 3, 969mm | |
| Cov pob | 25 | |
| Siv roj kom muaj nuj nqis | 0.96 cm3 | |
| foob | Tsis muaj | |
| Precision | P4A | |
Ntxiv 71907.ACB.HCP4A angular hu rau pob bearings 35 * 55 * 10
| Lub npe | Thawj qhov loj me | Basic load ntsuam xyuas | Ua tau nrawm | ||||
| dynamic | zoo li qub | Roj lubrication | Roj-cua lubrication | ||||
| d [mm] | D [mm] | B [mm] | C[kN] | C{{0} [kN] | [r/min] | [r/min] | |
| 71907 ACB/P4A | 35 | 55 | 10 | 4.88 | 3.45 | 30 000 | 48 000 |
| S71907 ACB/P4A | 35 | 55 | 10 | 4.88 | 3.45 | 30 000 | |
| 71907 ACB/HCP4A | 35 | 55 | 10 | 4.88 | 3.45 | 36 000 | 56 000 |
| S71907 ACB/HCP4A | 35 | 55 | 10 | 4.88 | 3.45 | 36 000 | |
| 71907 IB/P4A | 35 | 55 | 10 | 5.07 | 3.65 | 34 000 | 53 000 |
| S71907 CB/P4A | 35 | 55 | 10 | 5.07 | 3.65 | 34 000 | |
| 71907 IB/HCP4A | 35 | 55 | 10 | 5.07 | 3.65 | 40 000 | 63 000 |
| S71907 CB/HCP4A | 35 | 55 | 10 | 5.07 | 3.65 | 40 000 | |
| 71907 UAS/P4AH | 35 | 55 | 10 | 7.28 | 4.5 | 32 000 | 50 000 |
| 71907 UAS/P4AL | 35 | 55 | 10 | 7.28 | 4.5 | 32 000 | 50 000 |
| S71907 ACE/P4A | 35 | 55 | 10 | 7.28 | 4.5 | 32 000 | |
